Quick Details
Place of Origin:Hebei, China
Brand Name:FECT
Model Number:FT-GN-2515-B
Packaging Delivery
Selling Units:Multiple of 35
Package size per batch: 125X26.5X21 cm
Gross weight per batch:33.000 kg
Package Type:Packing Details:1.Cardboard2.Wood Pallet/Box,or according to your request.
common security export packing
Specification
item | Fire sprinkler patti building sprinkler fire system |
Place of Origin | China |
Hebei | |
Brand Name | FECT |
Model Number | FT-GN-2515-B |
Working Pressure | 200 psig |
Max. Temp. | 300 ℉ |
Inlet Size | 1 1/2" |
Total Length | 4 ft |
Max No. of 90° Bends | 3 |
Min Bend Radius | 4" |
Flexibility Type | Limited |
1.Technical data:
(1)Rated Pressure,psig：200
(2)Max. Ambient Temp,°F (°C)：300 (149)
(3)Nom. Inlet by Outlet Size, in.：1x1/2
(4)Assembly Length,ft(mm)：4.0 (1220)
(5)Max No. of 90°Bends：3
(6)Bend Radius, in.：4
(7)Equivalent Length of 1 in. Schedule 40 Steel Pipe (C = 120), ft：23
(8)Flexibility Type：Limited
2.Property advantages：
(1)more dependability
(2)Life span is longer
(3)The coupling is much stronger
(4)Lower expenditure
(5)Installation is much easier
